General parameters & standard parameters

Step angle

1.8°

Number of phases

2

Insulation resistance

100MΩmin. (500V DC)

Insulation level

Class B

Moment of inertia

3g.cm2

Weight

0.08kg

Drive motor

24V

Rated current

0.6A

Phase resistance

6Ω±10%

Phase inductance

2mH±20%

Holding torque

32mN.m

Position torque

4mN.m
